Pioneer® AV Receiver | 7.2 Channel x 165W

- By ordering this product with custom specifications you acknowledge that the sale is final and the product may not be returned or exchanged.

- Send us a sample of the wood that you would like the speaker to match. Your order will be placed on hold for up to 14 days as we wait for your wood sample. Samples not received after 14 days will cause your order to be canceled. Please send your physical sample along with a copy of your Triad Order attached to the address listed below.

Triad Speakers
Sales - RUSH - Paint Sample
15835 NE Cameron Blvd.
Portland, OR 97230
- Your order will be placed on hold for up to 14 days as we wait for your color sample. Samples not received after 14 days will cause your order to be canceled. Your sample must be of a solid color. Wood, multi colored wallpaper/fabrics and faux finishes CANNOT be sent as samples for custom paint matching. Please send your physical color sample along with a copy of your Triad Order attached to the address listed below.

Triad Speakers
Sales - RUSH - Paint Sample
15835 NE Cameron Blvd.
Portland, OR 97230

Add to cart
Description
Specs
Support
Description
Description

The Pioneer VSX-932 brings out the best in home audio via DTS:X™ and Dolby Atmos® technology. Featuring the Reflex Optimizer for Atmos-enabled speakers, Ultra HD video, HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision, this receiver offers a seamless way to integrate all your favorite systems.

Pioneer® AV Receiver | 7.2 Channel x 165W

The Pioneer VSX-932 brings out the best in home audio via DTS:X™ and Dolby Atmos® technology. Featuring the Reflex Optimizer for Atmos-enabled speakers, Ultra HD video, HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision, this receiver offers a seamless way to integrate all your favorite systems. Stream music to any room with FireConnect™, Chromecast built-in, and DTS Play-Fi®, or listen to a number of songs via internet radio and network streaming services, with smooth control on the Pioneer Remote App. Users can even connect a turntable via the phono input.

HDR10 & HDCP 2.2 Support

The VSX-932 supports passthrough for Dolby Vision, HLG (Hybrid Log-Gamma) and HDR10 signals. Connect a compatible source to enjoy these latest video standards on a compatible display. All HDMI terminals also support [email protected] 4:4:4 24-bit, Wide Color Gamut (BT.2020) and HDCP 2.2, so you can enjoy premium 4K content with the latest in digital copy protection.

Dolby ATMOS® Expands the Experience

With Dolby Atmos, sound comes from all directions, including overhead, to create a truly immersive experience with astonishing clarity, richness, and depth. The specific sounds of people, music, and action can be placed and moved all around you in three-dimensional space, so you feel like you’re inside the scene.

DTS:X™ Audio

DTS:X leverages object-based audio to enable new immersive and interactive audio experiences. Since DTS:X can automatically adapt the audio to the existing channels and speaker system, no specific speaker layout is required. Users will experience an immersive soundscape with incredibly rich and life-like audio.

MCAAC® Auto Room Tuning

Developed with the expertise of professional recording studios, Multi-Channel Acoustic Calibration System (MCAAC) automatically compensates for differences in speaker size, level and distance, and equalizes response. Whether your customer is watching the latest Hollywood blockbuster or enjoying high-resolution music, MCACC will make sure their home theater sounds its very best.

Phase Control Via Reflex Optimizer

When using Dolby Atmos-enabled speakers, different audio pathways cause a phase shift, making the sound feel uncomfortable. Using Phase Control technology, the Reflex Optimizer adjusts this shift, and improves the localization of the sound image by aligning all speakers frequencies with the frequency of the floor speakers. This creates an ideal audio reproduction environment.

Built-In Chromecast

Customers can use mobile devices to stream their favorite music, radio, or podcasts to a speaker through built-in Chromecast. Through app-compatible iOS and Android devices, plus Mac, Chromebook, and Windows PCs, Chromecast lets end users control audio from anywhere in the house. Many popular Chromecast-enabled apps are available at g.co/cast/audioapps.

Streaming Services & Internet Radio

This receiver offers a limitless flow of streaming music, sports, talk, and news entertainment from internet radio stations and online music services, including Pandora, Spotify, TuneIn, TIDAL, and Deezer. Please note: Pandora service is only available in the U.S.

No More Wires

Enjoy music wirelessly via built-in Wi-Fi and Bluetooth technology! Each receiver is compatible with iOS® and Android™ devices, BlackBerry®, laptops and more! Two antennas provide dual band Wi-Fi (2.4GHz and 5GHz) for a greater network range and throughput so everything streams smoothly.

New DAC Delivers Low Distortion

With a high-grade 384kHz/32bit digital to analog convert (DAC) produced by AKM, this receiver delivers clear, delicate audio reproduction provided by the unique digital filter so it achieves extremely low distortion.

Multi-Room Audio

Developed with the expertise of professional recording studios, Multi-Channel Acoustic Calibration System (MCAAC) automatically compensates for differences in speaker size, level and distance, and equalizes response. Whether your customer is watching the latest Hollywood blockbuster or enjoying high-resolution music, MCACC will make sure their home theater sounds its very best.

Support For The Latest Codecs

When using Dolby Atmos-enabled speakers, different audio pathways cause a phase shift, making the sound feel uncomfortable. Using Phase Control technology, the Reflex Optimizer adjusts this shift, and improves the localization of the sound image by aligning all speakers frequencies with the frequency of the floor speakers. This creates an ideal audio reproduction environment.

Uncompressed HD Audio

Customers can use mobile devices to stream their favorite music, radio, or podcasts to a speaker through built-in Chromecast. Through app-compatible iOS and Android devices, plus Mac, Chromebook, and Windows PCs, Chromecast lets end users control audio from anywhere in the house. Many popular Chromecast-enabled apps are available at g.co/cast/audioapps.

Package Contents:

  • (1) VSX-932
  • (1) MCACC Microphone with Wire
  • (1) Remote Control
  • (1) AA Batteries for Remote Control
  • (1) Manual
Specs
Specifications
P-VSX-932
4U
7.2-Channel
130W
HDMI Audio Return Channel (ARC)
Speaker B / Bi-Amp Mode: Yes
Digital Core Engine with Cirrus Logic (Quad Core) x1
384 kHz/32-bit DAC (AK4438)
Hi-Res Audio File Playback via USB/Network:
Up to 192 kHz/24-bit ALAC, AIFF, FLAC, WAV
5.6/2.8 MHz DSD Playback (except via Wireless LAN)
Dolby® TrueHD Playback (via USB only)

Works with Pioneer Remote App (iOS/Android) for Multi-room En
2.2
Digital Core Engine with Cirrus Logic (Quad Core) x1 384 kHz/32-bit DAC (AK4438)
Dolby Atmos® for 3.1.2ch/Dolby Surround
Surround Enhancer
DTS:X/DTS Neural:X
Reflex Optimizer
Dolby® TrueHD/Dolby Digital Plus
DTS-HD Master Audio/DTS-HD High Resolution Audio/DTS 96/24/DTS-ES
DTS-HD Express
DSD Disc (SACD) Playbac
MCACC Auto Room Tuning
Phase Control
Subwoofer EQ
Advanced Sound Retriever (2ch)
Advanced Surround Modes: Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Extended Mono, Front Stage Surround Advance
RCA Analog Audio In x3
RCA Analog Video In x2
3.5mm Analog Line In
Toslink x1 In
Coax x1 In
USB x2 In (front and rear)
Subwoofer x2 Out
Yes 4K/60p/4:4:4
4 In / 1 Out
Yes
36-bit
2.4GHz and 5GHz
RJ-45
Whole Home Audio with FireConnect (w/ future FW update)
Chromecast built-in (w/ future FW update)
DTS Play-Fi Ready (w/ future FW update)
Apple AirPlay Certified
Pandora®
Spotify®
TIDAL
Deezer
Internet Radio with TuneIn
Remote Control / Setup Microphone
Power Consumption: 480 W/ Standby: 0.15 W
17.12" x 6.81" x 12.61"
19.4 lb

Rack Spacing
Channels
Power Output
Audio Features
Audio Processor
Playback
HDCP Compliance
Decoders
Supported Audio Formats
Soundfield Calibration
Listening Modes
Connector Type
HDMI 4K Support
HDMI Connections
HDMI Deep Color Support
HDMI Max Color Depth
Wireless Features
Port Desc.
Streaming
Included Accessories
Power Consumption
Dimensions (W x H x D)
Weight
