Control4® DS2 Wedge Backplate 2-Modules

- By ordering this product with custom specifications you acknowledge that the sale is final and the product may not be returned or exchanged.

- Send us a sample of the wood that you would like the speaker to match. Your order will be placed on hold for up to 14 days as we wait for your wood sample. Samples not received after 14 days will cause your order to be canceled. Please send your physical sample along with a copy of your Triad Order attached to the address listed below.

Triad Speakers
Sales - RUSH - Paint Sample
15835 NE Cameron Blvd.
Portland, OR 97230
- Your order will be placed on hold for up to 14 days as we wait for your color sample. Samples not received after 14 days will cause your order to be canceled. Your sample must be of a solid color. Wood, multi colored wallpaper/fabrics and faux finishes CANNOT be sent as samples for custom paint matching. Please send your physical color sample along with a copy of your Triad Order attached to the address listed below.

Triad Speakers
Sales - RUSH - Paint Sample
15835 NE Cameron Blvd.
Portland, OR 97230

Add to cart
Description
Specs
Description
Description

This wall-mounted backplate features a 25° angle to offer better visual coverage of the entry area, especially in deployments with oversized or double-doors. This unit is only compatible with the DS2 2 Module intercom. The dimensions for the side mounted to the wall are 4.5 x 9.4 inches. The dimensions of the side the intercom mounts to are 4.1 x 9.2 inches.

Control4® DS2 Wedge Backplate 2-Modules

This wall-mounted backplate features a 25° angle to offer better visual coverage of the entry area, especially in deployments with oversized or double-doors. This unit is only compatible with the DS2 2 Module intercom. The dimensions for the side mounted to the wall are 4.5 x 9.4 inches. The dimensions of the side the intercom mounts to are 4.1 x 9.2 inches.

Image of animated person and a tree

Better Visual Coverage

The backplate is wall-mounted, and its angle (25°) offers better visual coverage of the area in front of an entry door.

Image of an animated triangle and arrow

Universally Reversible

This wedge backplate can be used to tilt the intercom left and right.

Image of two animated mount drawings

Cabling for Cavity

Thanks to its depth, it also serves as a cavity for hiding and terminating all cabling connected to the DS2 intercom.

Image of Image of a square with a dotted outline and a square with a solid line outline

Modular Configuration

Thanks to its unparalleled modularity, DS2 can be whatever you need it to be. Combine the Camera module with any additional modules, choose the right frames, and build the intercom you need!y.

Image of two animated mount drawings

Versatile Mounting Options

Flush or surface mounting: there are no limits with DS2. Just choose the correct frame and box that suit your needs. Mounting frames, backplates, and wall-boxes sold separately.

Image ofanimated rain cloud

Resistant to Any Environment

Be sure the keypad will work whenever it’s needed thanks to IP54 and IK08 certifications. The DS2 is ready to withstand any weather challenges - and can even survive vandal attacks! True reliability.

Specs
Specifications
C4-DS2-WB-2
Tilt: 25°
Wall side dimensions: 4.5 "x 9.4"
Intercom side dimensions: 4.5"x 9.2"

Angle
Dimensions (W x H x D)

Limited Hardware Warranty

Control4 warrants its hardware product to be free from defects in material and workmanship during the warranty period. If the hardware proves to be defective in material or workmanship during the warranty period, Control4 will, at its sole option, repair or replace the product with a like product. The warranty extends only to products purchased directly from Control4 Corporation or an Authorized Control4 Dealer. For complete limited warranty information, including details on purchaser legal rights as well as limited warranty exclusions, visit here.
