Description
The USB Expander expands the USB audio capability of a CONVERGE Pro 2 mixer by providing an additional USB audio interface with 2x2 channels.
ClearOne® CONVERGE USB Expander
The USB Expander expands the USB audio capability of a CONVERGE Pro 2 mixer by providing an additional USB audio interface with 2x2 channels. This device enables users in different rooms to run UC applications in laptops for a professional quality audio experience using a simple, flexible USB connection.
- 2 input channels (L&R) and 2 output channels (L&R) of 48kHz, 24-bit professional-quality audio.
- Useful for Unified Communications, video conferencing, audio playback and recording, and more.
- Can daisy-chain up to three USB expanders per CP2, and can also be daisy-chained with other P-link devices.
- Can be placed up to 200’ (60m) from CP2 or other P-link devices, extending a P-link chain.
- Compact form factor (1/3 RU) and flexible mounting (rack, under-table, wall, or ceiling).
- P-link or PoE injector for power and serial connection for control interface.
Specs
Specifications
| C1-CONV-USB-EXP |
|---|
USB-B Connector |
Compatible: USB 2.0, USB 3.0 |
48 kHz |
Power LED: Off: Not powered Solid Blue: Powered ON Status LED: Off: No P-Link plugged in Solid Blue: P-Link plugged in and system working normally Flashing Blue: Locate mode initiated from CP2 CONSOLE Software Red: Error c |
3 Position (Tx, Rx, Gnd) 3.81mm Grey Header, Male, Phoenix type Euroblock
connectors |
Rack-shelf, Under the table, wall mount, ceiling mount |
PoE/PoE+ Port Type:: RJ-45 802.3af or 802.3at PoE/PoE+ injector input |
P-LINK PERIPHERAL BUS: : Up to 200 feet (60 meters) |
100-240V AC, 50/60Hz |
3W |
Rack Mounting (Ears: Pre-installed, Qty 2 Input Connectors: 3.81mm Terminal Block Connector, 3 Position (Grey), Qty 1 USB Cable: USB Type A to Type B, 6 Ft (1.8M), Qty 1 |
14°F to 104°F (-10°C to 40°C) Ambient Temperature |
Without rack-ears: 5.5” x 1.6” x 4.1” or 14.4 x 4.2 x 10.3cm With rack-ears: 6.8” x 1.7” x 4.1” or 17.2 x 4.3 x 10.3cm |
0.88 lbs (0.4 kg) |
USB Ports |
USB Description |
Supported Sample Rates |
LED Indicators |
RS232 Control |
Mounting |
PoE Features |
Transmission Distance |
Voltage |
Power Consumption |
Included Accessories |
Operating Temperature |
Dimensions (W x H x D) |
Weight |
