The Araknis Networks® router is perfect for high traffic networks. It has 4 Gigabit LAN interfaces with full Gigabit LAN-LAN speed. It supports 2 Gigabit WAN interfaces that can be configured in load-balancing or link failover modes. The router has embedded firewall for added network security, and also supports a plethora of VPN technologies to allow remote access to client network. Best of all, it's OvrC enabled.
This Araknis Networks® router is perfect for high traffic networks. It has 4 Gigabit LAN interfaces with full Gigabit LAN-LAN speed. It supports 2 Gigabit WAN interfaces that can be configured in load-balancing or link failover modes. The router has embedded firewall for added network security, and also supports a plethora of VPN technologies to allow remote access to client network. Best of all, it's OvrC enabled. See how it compares to the competition >>
10/100/1000Mbps uplink to ensure full performance
Cloud-based customer management service engineered by SnapAV
SPI, DoS prevention, WAN Request Blocking, and content filtering
Router supports PPTP, IPSec, and OpenVPN for remote access
Connect the network to two different ISPs or configure your WAN links to load-balancing or link failover
This feature allows a dealer to connect the client network to two different ISPs (for example: TWC and Comcast) and have the WAN links configured either as load-balancing (i.e. active/active) or link failover (i.e. active/standby).
The router has an embedded 4 Gigabit switch on the LAN side. Use it to connect the router to multiple switches in the network or connect other devices to the router directly. The LAN side of the router supports full LAN-LAN Gigabit speed with Jumbo Frame support for better video streaming.
Araknis and OvrC allow your customers to filter and customize their location’s network content. Multiple filter levels range from basic malware protection to advanced content filtering, so customers can choose one that best fits their family.
Learn more about content filtering >>
*Currently in BETA
At 1U in height and rack ears for rack mounting, the router follows our standard design and allows for multiple mounting options.
The router features front blue LEDs and rear ports, giving you a nice clean finish every time.
Our router’s GUI is very user friendly and follows the Araknis standard design. This simple platform is very intuitive and easily explains the depth of features this product supports.
If you need to remotely access the client network via VPN, the router supports PPTP, IPSec, and OpenVPN technologies. OpenVPN is an easy, secure option that is backed up by the open source community.
An embedded firewall supports Stateful Packet Inspection (SPI), Denial of Service (DoS) prevention, WAN Request Blocking, and content filtering. Its layers of network security make it harder for hackers to attack so all your secrets stay secret.
Setting up port forwarding couldn't be easier with Araknis’ simplified GUI. Set up a range of external ports with a single command.
| AN-300-RT-4L2W |
|---|
32 MB |
CE, FCC, UL |
8.1" x 1.7" x 5.2" |
WAN Load-balancing WAN Link Failover Static Routing Inter-VLAN Routing 1:1 Nat Port Address Translation Port Trigger DMZ Host IPv6 |
10% - 80% Non-Condensing |
32°F - 104°F |
256 MB DDR2 |
Yes |
802.1Q |
Stateful Firewall Stateful Packet Inspections SoS Prevention Ping of Death SYN Flood IP Spoofing Port Forwarding Content Filtering (UR and Keyword) Access Control List UPnP Bonjour Auto Reboot |
Web Management SNMP: v1,2c,3 Email Alert Download/Upload Config File System Log HTTP and HTTPs System Time: NTP/Manually Cloud Management DHCP Client DHCP Relay DHCP Server DNS Relay |
Yes |
Yes |
12V 1A DC |
LAN - LAN Throughput: 1Gbps WAN - LAN Throughput: 492Mbps IPSec Throughput: 75Mbps |
Flash Memory |
Certifications |
Dimensions (W x H x D) |
Features |
Operating Humidity |
Operating Temperature |
SDRAM Memory |
DDNS Feature |
VLAN Features |
Security Features |
Management Features |
RJ45 Auto Sensing |
RJ45 Auto Negotiation |
External Power Supply |
Port Desc. |
Araknis Networks® products have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified, or disassembled. Products to be repaired under this warranty must be returned to Snap One or a designated service center with prior notification and an assigned return authorization number (RA).
