This high-performance extender delivers 4K HDR HDMI content up to 330ft reliably and effectively and supports bi-directional IR passthrough, CEC passthrough, RS232 pass through, and Ethernet passthrough. With bi-directional PoC supported, only one power adapter is needed. It also features HDMI IN audio de-embedding, allowing the extender to output both digital and analog audio via 3.5mm and Toslink.
This high-performance extender delivers 4K HDR HDMI content up to 330ft reliably and effectively and supports bi-directional IR passthrough, CEC passthrough, RS232 pass through, and Ethernet passthrough. With bi-directional PoC supported, only one power adapter is needed. It also features HDMI IN audio de-embedding, allowing the extender to output both digital and analog audio via 3.5mm and Toslink.
This extender offers full support of 4K@30Hz (including HDMI® with 3D), Deep Color (36bit), as well as support for Dolby® True HD, Dolby® Digital Plus, DTS™-HD Master and LPCM audio formats. This product is compatible with HDMI 2.0/ HDCP 2.2 products as well. This extender supports 4K@30 Hz (4:4:4), 4K@60 Hz (4:2:0), and 1080p up to 330ft. Please note: 4K support varies by distance and cable type. Please refer to specifications for further details.
No room for a bulky power supply behind the TV or in a rack? Not a problem. With Bi-Directional Power over Cable (POC), you can send power over the same Cat5e/6 cable that extends your video, audio, and control signals. This means you only need one power supply - and you can put it at the head end or display to get it completely out of the way. Plus, the extender features screw-down power plugs, so you never have to worry about getting service calls because a plug fell out when the TV was moved. Now those are some real reasons to celebrate!
Thanks to bi-directional IR and RS-232, you get no-hassle integration with a variety of control systems, and you can easily send IR signals from the TV location back to cable boxes, DVD players, and other source equipment at the head end. The IR connections feature active circuitry that supports a wide variety of IR and control system types.
Intelligent circuit design, perfected through extensive hardware testing, has resulted in a robust product with excellent ESD and surge protection that exceeds CE Level 3 standards. During development, every connection was tortured with an ESD gun and a lightning simulator. They were hit with ESD at 15KV and surges up to 1600V. More importantly, though, they each lived to tell about it!
For a high-tech way to transmit audio back to a centralized location, an AVR, or another system, use the ARC (Audio Return Channel) feature to send audio from a smart TV or another source in the viewing room back to the head end. It’s great for smart TVs, Blu-Ray players, or other content sources that stream original audio and video straight from the box. Plus, this extender also features audio de-embedding with 3.5mm or Toslink output on both the transmitter-side and receiver-side.
This extender features auto downscaling, which enables support for a complete range of digital and analog signals to ensure every source displays perfectly every time.
With DIP switch support, you can easily configure EDID, IR, RS232, and ARC functions for easy system setup.
In addition to extending the signal, this model has a handy local output that lets you loop back content to monitor the feed on a local display at the sender end.
Whether delivering content from a laptop in a boardroom or extending graphics in a command-and-control environment, the B-660-EXT-444-100AS has you covered with bi-directional RS-232 control, ethernet passthrough and its ability to deliver video formats up to 4K60Hz to accommodate the latest graphic requirements.
B-660-EXT-444-100AS |
---|
Transmitter: 1x HDMI IN, 1x HDBT OUT, 1x HDMI OUT, 1x IR Receiver,1x IR Flasher, 1x RS-232 (RJ45), 1x AUDIO OUT (3.5mm analog audio out), 1x SPDIF OUT, 2x ETHERNET, 1x DC 12V IN Receiver: 1x HDMI OUT, 1x HDBT IN, 1x IR Receiver, 1x IR Flasher, 1x RS-232 |
HDMI IN/OUT: Fully supports audio formats in HDMI 2.0 specification, including PCM 2.0/5.1/7.1, Dolby TrueHD™, Dolby Atmos™, DTS-HD Master Audio™ and DTS:X™ 3.5mm Analog AUDIO OUT: PCM 2.0 SPDIF: PCM 2.0, Dolby Digital™, DTS 5.1™ |
Human-body Model: ±15kV (Air-gap discharge) |
Cat 5e/6 100m/330ft Up to 1080P@60Hz 36bpp-70m/230ft 1080P@60Hz 48bpp Cat 6a/7 100m/330ft-4K@30Hz 24bpp 4K@60 4:2:0 24bpp 4K@60 4:4:4 24bpp HDMI Recommended max length of 3m/10ft All supported resolutions |
7.64 in. x 0.61 in. x 4.33 in. (Transmitter/Receiver, without
mounting ears) |
10% to 90%, non-condensing |
0°C to 40°C (32°F to 104°F) |
Receiver is powered by transmitter: 24.05W Transmitter is powered by receiver: 23.67W Transmitter and receiver are powered separately: Transmitter: 8.95W, Receiver: 11.05W |
-20°C to 60°C (-4°F to 140°F) |
0.93lb (0.42kg) |
HDMI IN & HDMI OUT: 18Gbps |
800x600, 1024x768, 1280x768, 1280x800, 1280x960, 1280x1024, 1360x768, 1366x768, 1440x900, 1600x900, 1600x1200, 1680x1050, 1920x1200, 2560x1440, 2560x1600 |
DC 12V 3A |
IR, RS-232, CEC, DIP Switches |
Connector Type |
Supported Formats |
ESD Protection |
Transmission Distance |
Dimensions (W x H x D) |
Operating Humidity |
Operating Temperature |
Power Consumption |
Storage Temperature |
Weight |
Data Transfer Rate |
VESA Resolution |
External Power Supply |
Controls |
This Binary™ product has a 2-year limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty will not apply to products that have been abused, modified or disassembled. Products to be repaired under this warranty must be returned to Snap One or a designated service center with prior notification and an assigned return authorization number (RA).
