KEF T Series Shallow Depth In-Ceiling Speaker (Each)
KEF-CI160TR
Click to enlarge
Description
Specs
Support
Description
Description
KEF's Ci160TR/160TS solves installation issues where cavity depth is a problem!
KEF T Series Shallow Depth In-Ceiling Speaker (Each)
KEF's Ci160TR/TS solves installation issues where cavity depth is a problem! Requiring a minuscule 36mm deep cavity for mounting and featuring KEF's formidable 4.5in. mid/bass T Series driver and powerful 1in. tweeter, the ultra-slim speaker makes KEF’s uncompromised sound quality available even in applications where ceiling space is at a premium.
T Series Ultra-Thin
Boasting the latest incarnation of our formidable 4.5in. mid/bass T Series driver and powerful 1in. tweeter, the ultra-slim T Series Ci speakers open up new possibilities for enjoying KEF’s uncompromised sound quality where space above the ceiling is at a premium. Requiring less than 36mm of mounting depth, the Ci160TR/TS fits snugly in very narrow ceiling spaces and is therefore specified for demanding applications such as today’s luxury high-rise apartments and your music system.
Key Features
- Less than 36mm mounting depth allows fitment to very restricted cavities
- Ultra-low profile LF unit with excellent bass extension
- Vented tweeter with KEF's unique 'tangerine' waveguide for natural HF response and wide, even dispersion
- Rigid flat diaphragm assures clean upper bass and mid-range response
- Paintable Ultra-Thin Bezel (UTB) and magnetic grille to blend unobtrusively with décor
- Fast, versatile installation on virtually any surface via dogleg or direct screw fastening
Where the Pros Buy Audio
Grow your audio business with our curated selection of unique speaker brands. After all, the best speaker option is the one you need for the job.
Learn more
Specs
Specifications
| KEF-CI160TR | KEF-Ci160TS |
|---|---|
LF: 4.5" dual layer MF HF: 1" aluminium HF |
LF: 4.5" dual layer MF HF: 1" aluminium HF |
8Ω |
8Ω |
87dB |
87dB |
110Hz-24kHz (±6dB) |
110Hz-24kHz (±6dB) |
1.7kHz |
1.7kHz |
Power: 10-100W |
Power: 10-100W |
Minimum wall thickness: .39" Maximum wall thickness: 1" Optional rough in frame: KEF-RIF160R Optional rear enclosure: KEF-RNC160R |
Minimum wall thickness: N/A Maximum wall thickness: N/A Optional rough in frame: KEF-RIF160S Optional rear enclosure: KEF-RNC160S |
9.24" |
8.77" |
7.7" |
7.64" |
1.57" |
1.61" |
1.42" |
N/A |
2.2 lb |
2.3 lb |
Drive Units |
Nominal Impedance |
Sensitivity |
Frequency Response |
Crossover Frequency |
Amplifier Requirements |
Installation |
Diameter |
Cutout Diameter |
Depth |
Mounting Depth |
Weight |
