Araknis Networks® Wi-Fi 6 820 Series Indoor Wireless Access Point

- By ordering this product with custom specifications you acknowledge that the sale is final and the product may not be returned or exchanged.

- Send us a sample of the wood that you would like the speaker to match. Your order will be placed on hold for up to 14 days as we wait for your wood sample. Samples not received after 14 days will cause your order to be canceled. Please send your physical sample along with a copy of your Triad Order attached to the address listed below.

Triad Speakers
Sales - RUSH - Paint Sample
15835 NE Cameron Blvd.
Portland, OR 97230
- Your order will be placed on hold for up to 14 days as we wait for your color sample. Samples not received after 14 days will cause your order to be canceled. Your sample must be of a solid color. Wood, multi colored wallpaper/fabrics and faux finishes CANNOT be sent as samples for custom paint matching. Please send your physical color sample along with a copy of your Triad Order attached to the address listed below.

Triad Speakers
Sales - RUSH - Paint Sample
15835 NE Cameron Blvd.
Portland, OR 97230

Add to cart
Description
Specs
Support
Description
Description

The Araknis AN-820 Wireless Access Point brings the latest in Wi-Fi technology to the Araknis lineup! Wi-Fi 6 offers support for OFDMA, MU-MIMO, 1024 QAM, and BSS Coloring to help support higher network capacity and enhanced reliability. The AN-820 features a 2.5Gbps LAN port-in and offers support for multi-gig jobs.

Araknis Networks® Wi-Fi 6 820 Series Indoor Wireless Access Point

The Araknis AN-820 Wireless Access Point brings the latest in Wi-Fi technology to the Araknis lineup! Wi-Fi 6 offers support for OFDMA, MU-MIMO, 1024 QAM, and BSS Coloring to help support higher network capacity and enhanced reliability. The AN-820 features a 2.5Gbps LAN port-in and offers support for multi-gig jobs.

Important Note: Mixing Araknis Wi-Fi 6 and Wi-Fi 5 Series Access Points on the same job will impact performance and is not recommended. Fast roaming between Wi-Fi 6 and Wi-Fi 5 devices is not supported.
Wifi 6 graphic

A Fast & Efficient Network

Wi-Fi 6 is the new standard for increased speed, coverage, and capacity. Installing a Wi-Fi 6 access point in your networks can also extend the battery life of Wi-Fi 6-connected devices.

The AN-820's 4x4 antenna provides a more powerful connection for more devices, making sure your network won't sacrifice speed for size.

Person using OvrC on desktop and mobile phone

Easy Setup with OvrC Wi-Fi Management

The lightning-fast speeds of Wi-Fi 6 combined with the unmatched control provided by OvrC Wi-Fi management delivers enhanced performance and convenience to your networking portfolio. With cloud configuration for projects with multiple access points, you can easily configure, manage, monitor, and troubleshoot the network from the OvrC mobile or web app, eliminating hours of manual setup time.

For added efficiency, the new OvrC Connect app empowers your clients to resolve common issues on their own.

OFDMA graphic

Powerful & Reliable Performance

We’re placing greater demand on the network than ever before. Wi-Fi 6 utilizes OFDMA (orthogonal frequency-division multiple access) to tackle high-density environments by allowing simultaneous communication between multiple devices. This technology helps optimize bandwidth, thereby reducing congestion and improving speeds.

2.5GbE graphic

Multi-Gig Port

The 2.5GbE Ethernet ensures the backhaul will not be a bottleneck for full use of available Wi-Fi capacity and helps futureproof your networks for applications such as VR/AR.

*Note: The 2.5GbE port is backward compatible with 100/1000Mbps Ethernet.

WOFDMA graphic

Pro-Friendly Features

Create multiple SSIDs and customize each to meet specific network requirements such as enabling/disabling Fast Roaming, Band Steering, or Wi-Fi 6 compatibility per SSID. This ensures the best Wi-Fi experience and provides tools necessary to support older IoT devices without impacting the main network.

This AP also offers DFS (Dynamic Frequency Selection) channel support to increase the number of Wi-Fi channels when available and WPA3 mode to offer latest security.

2.5GbE graphic

Pro-Friendly Design

The latest addition to the Araknis family shares the same bracket size and low-profile design as Araknis 810 APs to make upgrading a breeze.

As a bonus, the new Factory Reset button design no longer requires a pin saving time when performing hard resets.

Specs
Specifications
AN-820-AP-I
4x4
802.11 a/b/g/n/ac/ax
1 x 2.5G BASE-T Ethernet (RJ45)
1 x 1G BASE-T Ethernet (RJ45)
Power over Ethernet (802.3af/at/bt)
Full Functionality:
- DC Power 12V/4A : 25.3W
- 802.3at (PoE+): 25.22W
Limited Functionality:
- 802.3af (PoE)
Embedded Antenna, Omni-Directional
2.4GHz: 1148Mbps
5GHz: 2400Mbps
2.4Ghz: Up to 1024-QAM
5GHz: Up to 1024-QAM
20, 40, 80MHz
2.4GHz: 25dBm
5GHz: 25dBm
Auto Channel Selection
Operation Modes: Access Point
Multiple SSIDs: up to 18 per AP
Wireless Security: WPA Mixed, WPA-PSK Mixed, WPA2 AES, WPA2-PSK AES, WPA3, WPA3-SAE, WPA3-SAE Mixed MAC Address Filtering
Hide SSID
Guest Network Bea
802.1Q (1 per BSSID)
Yes
Rate Limiting
L2 Access Control List
WiFi Scheduler
Max Client Limit
Wireless Client Isolation
FCC DFS, IC DFS, CE DFS, AS DFS, Wi-Fi 6 CERTIFIED, WMM, WPA/WPA2/WPA3, IEC 60950-1, IEC 62368-1 3rd
12V 4A DC
0˚C (32˚F) - 50˚C (122˚F)
Up to 90% non-condensing
. -4-140°F
2.82 lbs
9.29in (L) x 9.29in (W) x 1.89in (H)

Antenna
Wireless Mode(s)
Ethernet
PoE Features
PoE Consumption
Antennas
PHY Data Rate
Operating Frequencies
Channelization
Max TX Power
Wireless Features
VLAN Features
Spanning Tree
Management Features
Certifications
Line Voltage
Operating Temperature
Operating Humidity
Storage Temperature
Weight
Diameter

2-Year Limited Warranty

Araknis Networks® products have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified, or disassembled. Products to be repaired under this warranty must be returned to Snap One or a designated service center with prior notification and an assigned return authorization number (RA).
