The MM540 Enhanced Mount provides true safety, complete functionality, patented engineering and craftsmanship, plus the premium features that include heat sensing handles, paintable wall covers and a built-in sound-bar attachment.
MantelMount Enhanced Pull Down TV Mount
The MM540 Enhanced Mount provides true safety, complete functionality, patented engineering and craftsmanship, plus the premium features that include heat sensing handles, paintable wall covers and a built-in sound-bar attachment.
Swivel Angle - If recessing the MM540 with the RB100 Recess Box, maximum swivel is 35 degrees in both directions. The swivel extender kit included with the MM540 will not will not be usable if the mount is recessed.
Heat Sensing Handles
Handles turn red if the temperature reaches 110°.
2 Automotive Gas Pistons
Makes TV feel feather light.
Features
- Post Leveling - Provides the ability to easily level the TV after installation is complete without having to remove the TV.
- Paintable Wall Covers - Conceals the TV mount’s wall hardware.
- Cable Management - Tabs keep TV wires organized.
- Hard Travel Limit Stops - Manually set vertical and horizontal travel stops to assure your TV doesn’t hit your mantel or wall.
- Enhanced Stabilization - (Patent Pending) Maintains a level TV over time.
- Built-In Sound Bar Adapter - No additional hardware required.
Compatible Accessories
- MM-SBXL -Two brackets that accommodate sound bars larger than 29” wide and 5” tall. Can be used above or below TV, with a max load of 20 lbs.
- MM-EC43 - Create a hidden reusable channel to route signal cables through the wall behind a MantelMount.
- MM-SSB40 - Used in conjunction with the MM340 Mount or MM540 Mount and the RB100 Recess Box.
- MM-RBE10 - Easily reaches two studs that are farther than 18” apart. Used exclusively with the MM-RB100.
- MM-GS60 - Supports upper portion of thin glass panel TV’s. Attaches to all MantelMount mounts.
- MM-RB100 - Provides the flushest TV-to-wall storage on the market by allowing the MantelMount center arm to now fold into the wall. Used with the MM700, MM710 and must be paired with the SSB40 when used with the MM340 and MM540.
- MM-AB40 - Provides 90° bridge between lifting arm and wall plate, allowing it to attach to a horizontal surface. Ideal for alcoves/recessed wall treatments.
Specs
Specifications
| MM-540 |
|---|
44" |
80" |
90 lb |
Heavy Duty Steel (2.5mm) |
200x200, 200x300, 300x100, 300x200, 300x300, 400x200, 400x300, 400x400, 500x200, 500x300, 500x400, 500x500, 600x200, 600x300, 600x400, 600x500, 600x600 |
Vertical Drop: ±27" |
19" |
±60° |
±9° |
Flush-to-Wall Distance 5.7" |
34" x 25" x 5.5" |
38 lb |
Minimum TV Size |
Maximum TV Size |
Maximum Load Support |
Construction |
VESA Mounting Pattern |
Features |
Distance Extended |
Swivel |
Tilt |
Flush Mount Dimensions |
Dimensions (W x H x D) |
Weight |
