Description
Description
The MantelMount MM720 Pro Series Pull Down TV Mount offers patent-pending, quick & easy tilt functionality literally at your fingertips. Simply stand in front of your TV, squeeze the handle at the bottom of the screen, push or pull to the desired tilt, and let go to lock in the perfect tilt into place.
MantelMount MM720 Pro Series Pull Down TV Mount
The MantelMount MM720 Pro Series Pull Down TV Mount offers patent-pending, quick & easy tilt functionality literally at your fingertips. Simply stand in front of your TV, squeeze the handle at the bottom of the screen, push or pull to the desired tilt, and let go to lock in the perfect tilt into place.
Specifications
Features
- Quick and Easy Tilt Adjustment – Allows for quick and easy tilt adjustment up to 9° with one hand in front of the television.
- Optional Hide-Away Handle – The MM720 includes an optional hidden handle that, when installed, is not visible from the front of the TV.
- 2 Automotive Gas Pistons – Makes TVs feel feather-light.
- Enhanced Stabilization – (Patent Pending) Maintains a level TV over time.
- Heat Sensing Handle – Handles turn red if the temperature reaches 110°F.
- 80° Enhanced Swivel – The included SRE000 adaptor extends the swivel range for viewing from an adjacent area.
- Hard Travel Limit Stops – Manually set vertical and horizontal travel stops to assure your TV doesn’t hit your mantel or wall.
- Patented Auto Straightening – As TV is lifted to its highest raised state, it will automatically straighten.
- Cable Management & Paintable Wall Covers – Completes the installation by organizing TV wires and concealing the mounts wall hardware.
- Built-In Sound Bar Adapter – Accommodates soundbars up to 40".
Compatible Accessories
- MM-SBXL – Two brackets that accommodate sound bars larger than 29” wide and 5” tall. Can be used above or below TV, with a max load of 20 lbs.
- MM-RB100 – Provides the flushest TV-to-wall storage on the market by allowing the MantelMount center arm to now fold into the wall.
- MM-EC43 – Create a hidden reusable channel to route signal cables through the wall behind a MantelMount.
- MM-GS60 – Supports upper portion of thin glass panel TV’s. Attaches to all MantelMount mounts.
- MM-RBE10 – Easily reaches two studs that are farther than 18” apart. Used with MM-RB100.
Specs
Specifications
| MM-720 |
|---|
50" |
90" |
115 lb |
Heavy Duty Steel (3mm) |
200x200, 200x300, 300x100, 300x200, 300x300, 400x200, 400x300, 400x400, 500x200, 500x300, 500x400, 500x500, 600x200, 600x300, 600x400, 600x500, 600x600 |
Maximum Lowering Distance: 27” Vertical in all positions: (9° tilt function) |
15-19" |
30° Left and 30° Right (or)
80° Left and Right with
Swivel Extender |
±9° |
Flush-to-Wall Distance 5.4" |
39" x 16" x 6.3" |
38 lb |
Minimum TV Size |
Maximum TV Size |
Maximum Load Support |
Construction |
VESA Mounting Pattern |
Features |
Distance Extended |
Swivel |
Tilt |
Flush Mount Dimensions |
Dimensions (W x H x D) |
Weight |
